The Foam Concentrate Test Kit is suitable for testing the following properties of Foam Concentrate:

• Specific gravity
• 25% drainage time

• Expansion ratio
• Induction percentage

For those with access to a laboratory, the manual includes “how to” descriptions for testing:

• pH (requires a pH meter)
• Surface tension (requires a surface tension balance)
• Viscosity (requires a viscometer)

Suitable for testing the following types of foam:

• Aqueous Film-Forming Foams (AFFFs)
• Protein (FPs, FFFPs)
• Alcohol Resistant Foams - but not suitable for testing Specific gravity of AR Foams

Designed to test Produced Foams in accordance with International Standards NFPA 11: 2021 (paragraph 13.2.1) and BS EN 13565-1: 2019 (paragraph 5.3).

• Digital refractometer x 1
• Mechanical scales x 1
• Masses (weights) for scales x 3
• Digital stopwatch x 1
• NFPA 11 Foam Collection Cylinder with tube & tap x 1
• NFPA 11 Foam Collection Stand x 1
• 100ml cylinder x 3
• 200ml beaker x 1
• 500ml beaker x 1
• 1.000-1.050 hydrometer x 1
• 1.050-1.100 hydrometer x 1
• 1.100-1.150 hydrometer x 1
• 1.150-1.200 hydrometer x 1
• Conical measure x 1
• Thermometer x 1
• 1ml syringe x 1
• Sample bottles x 3
• Carrying case x 1
• Concentrate Testing Manual x 1
• Produced Foam Testing Manual x 1

• Gross weight: 18kg
• Overall dimensions: 57.5 x 52 x 34cm

• It is highly recommended that Foam samples are always sent to a reputable Foam Test Laboratory for independent, third party evaluation on at least an annual basis.


• Oil Technics (Fire Fighting Products) Ltd cannot be held responsible for any incorrect use or any incorrect results derived from using its Foam Test Kits or Foam Test Equipment; or for any loss, personal injury or property damage, however caused, resulting from the use of our Test Kits or Equipment.


• Please note: images/pictures are for illustrative purposes only. Actual kits may differ in terms of the specific brand of equipment provided.
